Standard Features
| Crane Boom | Max. Lifting Capacity | 260 t × 4.6 m |
|---|---|---|
| Max. Length | 91.4 m | |
| Fixed Jib | Max. Lifting Capacity | 27.0 t × 10.4 m |
| Max. Combination | 76.2 m + 30.5 m | |
| Luffing Boom : OPTIONAL | Max. Lifting Capacity | 150 t × 7.0 m |
| Max. Length | 61.0 m | |
| Long Boom : OPTIONAL | Max. Lifting Capacity | 47.1 t × 12.8 m |
| Max. Length | 91.4 m | |
| Luffing Jib : OPTIONAL | Max. Lifting Capacity | 80 t × 9.8 m |
| Max. Combination | 61.0 m + 61.0 m | |
| Main & Aux. Winch |
Max. Line Speed | 100 m/min (1st layer) |
| Rated Line Pull (Single Line) |
132 kN {13.5 tf} | |
| Wire Rope Diameter | 25.4 mm | |
| Wire Rope Length | 480 m (Main), 390 m (Aux.) |
|
| Brake Type | Spring-set hydraulically releasad(Negative) | |
| Working Speed | Swing Speed | 2.0 min-1 {2.0rpm} |
| Travel Speed | 1.1 / 0.7 km/h | |
| Power Plant | Model | HINO P11C-UN |
| Engine Output | 247 kW / 2,000 min-1 {rpm} | |
| Fuel Tank Capacity | 370 liters | |
| Hydraulic System | Main Pumps | 4 variable displacement |
| Max. Pressure | 31.9 MPa {325 kgf/cm2} |
|
| Hydraulic Tank Capacity | 600 liters | |
| Self-Removal Device | Standard counterweight removal | |
| Weight | Operating Weight* | Approx. 214 t |
| Ground Pressure | 109 kPa {1.11 kgf/cm2} | |
| Counterweight | 90.0t (Upper) + 24.0t (Lower) | |
| Transport Weight** | Approx. 46.0 t | |
